Mackinac Bridge
The Mackinac Bridge is currently the third-longest suspension bridge in the world. The Mackinac Bridge is the longest suspension bridge in the western hemisphere.
The total length is 26,372 feet. The length of the suspension bridge (including anchorages) is 8,614 feet. The length from cable bent pier to cable bent pier is 7,400 feet. The length of the main span (between towers) is 3,800 feet.
The width of the roadway is 54 feet. The outside lanes are 12 feet wide (2), the inside lanes are 11 feet wide (2), the center mall is 2 feet wide, and the catwalk, curb, and rail width is 3 feet on each side - totaling 54 feet. The stiffening truss width in the suspended span is 68 feet wide making it wider than the roadway it supports.
The height of the roadway at mid-span is approximately 200 feet above water level. The vertical clearance at normal temperature is 155 feet at the center of the main suspension span and 135 feet at the boundaries of the 3,000 ft. navigation channel.
